Intellinet 5-Port Gigabit Switch with PoE Passthrough, One IEEE 802.3bt (PoE++ / 4PPoE) PD PoE Port with 95 W Power Input, Four PSE PoE ports, PoE Power Budget up to 65 W, IEEE 802.3at/af Compliant Output, Desktop, Wall-mount Option
€112.09
Shipping from warehouse: A3
Estimated shipping: Tue, Nov 26 - Fri, Nov 29
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Intellinet
- Product code:
- 561808 / 0766623561808
Share this product:
Specification
| 10g support: | No |
|---|---|
| Ac input frequency: | 50 - 60 Hz |
| Ac input voltage: | 100 - 240 V |
| Basic switching rj-45 ethernet ports quantity: | 5 |
| Basic switching rj-45 ethernet ports type: | Gigabit Ethernet (10/100/1000) |
| Cable types supported: | Cat3, Cat5, Cat5e |
| Cables included: | AC |
| Copper ethernet cabling technology: | 100BASE-TX, 10BASE-T, 1000BASE-T |
| Depth: | 93 mm |
| Flow control support: | Yes |
| Full duplex: | Yes |
| Height: | 32 mm |
| Housing material: | Metal |
| Jumbo frames support: | Yes |
| Led indicators: | Activity, Link, PoE, Power |
| Mac address table: | 2048 entries |
| Manual: | Yes |
| Networking standards: | IEEE 802.3u, IEEE 802.3at, IEEE 802.3x, IEEE 802.3af, IEEE 802.3bt, IEEE 802.3, IEEE 802.3ab |
| Operating relative humidity (h-h): | 10 - 90% |
| Operating temperature (t-t): | 0 - 40 °C |
| Package weight: | 900 g |
| Packet buffer memory: | 1 MB |
| Packet forwarding rate (1 gbps): | 1488000 pps |
| Packet forwarding rate (10 mbps): | 14880 pps |
| Packet forwarding rate (100 mbps): | 148800 pps |
| Power consumption (max): | 72 W |
| Power over ethernet (poe): | Yes |
| Power source: | AC |
| Power supply included: | Yes |
| Storage temperature (t-t): | 0 - 70 °C |
| Store-and-forward: | Yes |
| Switching capacity: | 10 Gbit/s |
| Total power over ethernet (poe) budget: | 65 W |
| Wall mountable: | Yes |
| Weight: | 400 g |
| Width: | 168 mm |
