Intel Xeon E-2324G processor 3.1 GHz 8 MB Smart Cache
€350.86
Shipping from warehouse: A3
Estimated shipping: Tue, Dec 24 - Fri, Dec 27
14 days returnUnconditional return policy
- Availability:
- large quantity
- Brand:
- Intel
- Product code:
- CM8070804496015 /
Share this product:
Specification
| Box: | No |
|---|---|
| Commodity classification automated tracking system (ccats): | G167599 |
| Component for: | Server/workstation |
| Cooler included: | No |
| Cpu configuration (max): | 1 |
| Discrete graphics card: | No |
| Discrete graphics card model: | Not available |
| Ecc: | Yes |
| Enhanced intel speedstep technology: | Yes |
| Execute disable bit: | Yes |
| Export control classification number (eccn): | 5A992CN3 |
| Harmonized system (hs) code: | 85423119 |
| Idle states: | Yes |
| Intel 64: | Yes |
| Intel clear video technology: | Yes |
| Intel software guard extensions (intel sgx): | Yes |
| Intel trusted execution technology: | Yes |
| Intel virtualization technology (vt-x): | Yes |
| Intel virtualization technology for directed i/o (vt-d): | Yes |
| Intel vt-x with extended page tables (ept): | Yes |
| Intel® aes new instructions (intel® aes-ni): | Yes |
| Intel® boot guard: | Yes |
| Intel® clear video hd technology (intel® cvt hd): | Yes |
| Intel® hyper threading technology (intel® ht technology): | No |
| Intel® intru™ 3d technology: | Yes |
| Intel® memory protection extensions (intel® mpx): | Yes |
| Intel® optane™ dc persistent memory supported: | No |
| Intel® os guard: | Yes |
| Intel® quick sync video technology: | Yes |
| Intel® secure key: | Yes |
| Intel® transactional synchronization extensions: | No |
| Intel® turbo boost technology: | 2.0 |
| Intel® turbo boost technology 2.0 frequency: | 4.6 GHz |
| Intel® vpro™ platform eligibility: | Yes |
| Launch date: | Q3'21 |
| Market segment: | Server |
| Maximum enclave size support for intel® sgx: | 0.5 GB |
| Maximum internal memory: | 128 GB |
| Maximum internal memory supported by processor: | 128 GB |
| Maximum number of pci express lanes: | 20 |
| Maximum on-board graphics card memory: | 64 GB |
| Memory channels: | Dual-channel |
| Memory types supported by processor: | DDR4-SDRAM |
| Number of execution units: | 32 |
| On-board graphics card: | Yes |
| On-board graphics card 4k support: | Yes |
| On-board graphics card base frequency: | 350 MHz |
| On-board graphics card dynamic frequency (max): | 1300 MHz |
| On-board graphics card model: | Intel UHD Graphics P750 |
| On-board graphics card opengl version: | 4.5 |
| On-board graphics card refresh rate at maximum resolution (displayport): | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (edp - integrated flat panel): | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (hdmi): | 60 Hz |
| Pci express configurations: | 1x16+1x4, 2x8+1x4, 1x8+3x4 |
| Pci express slots version: | 4.0 |
| Processor ark id: | 212255 |
| Processor base frequency: | 3.1 GHz |
| Processor boost frequency: | 4.6 GHz |
| Processor cache: | 8 MB |
| Processor cache type: | Smart Cache |
| Processor cores: | 4 |
| Processor family: | Intel Xeon E |
| Processor lithography: | 14 nm |
| Processor manufacturer: | Intel |
| Processor model: | E-2324G |
| Processor operating modes: | 64-bit |
| Processor package size: | 37.5 x 37.5 mm |
| Processor socket: | LGA 1200 (Socket H5) |
| Processor threads: | 4 |
| Scalability: | 1S |
| Servicing status: | Baseline Servicing |
| Status: | Launched |
| Supported instruction sets: | AVX-512, SSE4.1, AVX 2.0, SSE4.2 |
| Supported memory types: | DDR4-SDRAM |
| System bus rate: | 8 GT/s |
| Thermal design power (tdp): | 65 W |
| Thermal monitoring technologies: | Yes |
| Tjunction: | 100 °C |
