Technical data:
Index Number YT-1706
UNIT PCA
Gross Weight (kg) 10.5000
Master Carton MC 2
Pal 84
Construction / post type
Piston length [mm] 154
Maximum thread length [mm] 113
Maximum height [mm] 498
Color box
Type of piston rod coating electroless nickel plating
Head diameter [mm] 56
Base dimensions [mm] 140x142
Max height [mm] 498
Height min [mm] 231
Loading capacity [kg] 15 000
Description:
Professional YATO post lift. It has a system of valves that precisely dose the oil stream, which, despite the small stroke of the piston, ensures its high performance under maximum load. It is characterized by small size and weight, which is important in moving and storing. Indispensable in car workshops and vehicle service stations.
Contents
- post lift
- lift arm
- instruction manual
- warranty card
