Hybrid inverter V-TAC DEYE SG03LP1 (SUN-3.6K-SG03LP1-EU) Three-phase inverter 3.6KW ON GRID/OFF GRID SKU 11725) Whit
€1,193.54
Shipping from warehouse: A3
Estimated shipping: Tue, Nov 26 - Fri, Nov 29
14 days returnUnconditional return policy
- Availability:
- large quantity
- Brand:
- V-tac
- Product code:
- SKU11725 / 3800170202658
Share this product:
Specification
| Battery temperature sensor: | Yes |
|---|---|
| Battery voltage range: | 40 - 60 V |
| Built-in display: | LCD |
| Certificates: | CE, EMC, RoHS |
| Cooling type: | Natural |
| Dc voltage range: | 350 - 650 V |
| Depth: | 281 mm |
| Height: | 702 mm |
| Input current: | 13 + 13 A |
| International protection (ip) code: | IP65 |
| Maximum ac current: | 11.4 / 10.9 A |
| Maximum charging current: | 90 A |
| Maximum continuous ac current: | 50 A |
| Maximum discharge current: | 90 A |
| Maximum input power (dc): | 6500 W |
| Maximum output power: | 5500 W |
| Mppt voltage range: | 200 - 650 V |
| Noise level: | 45 dB |
| Nominal input voltage: | 550 V |
| Number of mpp trackers: | 2 |
| Number of phases: | 3 |
| Operating temperature (t-t): | -25 - 60 °C |
| Overcurrent protection: | Yes |
| Overvoltage protection: | Y |
| Polarity reverse circuit protection: | Yes |
| Power current type: | DC/AC |
| Product colour: | White |
| Protection class: | II |
| Rated ac output power: | 5000 W |
| Rated current: | 7.6 / 7.3 A |
| Short circuit protection: | Yes |
| Standard interfaces: | RS485, CAN |
| Starting voltage: | 160 V |
| Strings for mpp tracker: | 1+1 |
| Touchscreen: | Yes |
| Weight: | 33.6 kg |
| Width: | 422 mm |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
