Machine tap for through holes, solid carbide
Design: factory standard, ISO 2/6H tolerance field, H type, section shape D (4–5 turns).
Application: for metric threads according to ISO DIN 13. Designed especially for steel with max. hardness 62 HRC.
Note: deviation of the diameter of the hole for thread (see table). The corresponding twist drill (Article code 1189) must be ordered separately.
HV full aluminium tap TiCN HRC62M10 GÜHRING
€236.05
Shipping from warehouse: B6
Estimated shipping: Fri, Nov 15 - Mon, Nov 18
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- GÜHRING
- Product code:
- 9029440100000 / 4031093621342
Share this product:
Specification
| Hardened steel < 55 hrc: | 4 |
|---|---|
| Hardened steel < 60 hrc: | 2, 2 |
| Jump: | 1.50 mm |
| Overall length: | 100 mm |
| Shank diameter: | 10.0 mm |
| Square grip: | 8.0 mm |
| Thread: | M10 |
| Thread hole diameter: | 8.60 mm |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
