Twisting drill, with Morse cone grip
Design: right-handed, precise top grinding and very high heat resistance. No correction. Lateral rake angle greater than normal, core thickness reduced, core convergence normal.
Application: designed especially for stainless steel, acid-resistant, heat-resistant and austenitic (INOX).
Hollow drill DIN345, HSSCo5, ground, type INOX, shank MK 14,0mm GÜHRING
This product is not available
- Availability:
- expected delivery
- Brand:
- GÜHRING
- Product code:
- 9012620140000 / 4031093303897
Share this product:
Specification
| Aluminium > 8% silicon: | 70 |
|---|---|
| Copper alloys: | 60 |
| Grip ø d2 = h6: | 1 |
| Inox austenite.: | 14 |
| Inox duplex: | 16 |
| Inox ferrite./martenz.: | 18 |
| Inox ferrite./martenz. f: | 0.200 mm/rev. |
| Ø h7: | 14.00 mm |
| Overall length: | 189 mm |
| Spiral length: | 108 mm |
| Steel < 1000 n/mm2: | 30 |
| Steel < 700 n/mm2: | 40 |
| Titanium > 850 n/mm2: | 10 |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
