Twisting drill, cylindrical shank
Execution: DIN 340, type N.
Right-handed, with precise grinding of the top. Lateral approach angle normal, core thickness normal, convergence greater than normal.
Application: designed in particular for deep hole drilling, in alloyed and non-alloy steels and castings with a strength exceeding 800 N/mm2, for ductile iron ductile iron, sintered cast iron, high-nickel brass and graphite.
Note: other dimensions available on request.
Hollow drill DIN340 HSS, ground type N 2mm GÜHRING
€3.53
Shipping from warehouse: B6
Estimated shipping: Tue, Dec 24 - Fri, Dec 27
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- GÜHRING
- Product code:
- 9002170020000 / 4031093042468
Share this product:
Specification
| Aluminium < 8% krzemu: | 45 |
|---|---|
| Cast iron gg/gts: | 27 |
| Execution: | Uncoated surface |
| Ggg cast iron: | 18 |
| Ø h7: | 2.0 mm |
| Overall length: | 85 mm |
| Spiral length: | 56 mm |
| Steel < 1000 n/mm2: | 20 |
| Steel < 700 n/mm2: | 22 |
| Steel < 700 n/mm2 f: | 0.050 mm/rev. |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
