Technical data:
Power:
Type of power supply: electric
Voltage: 220 - 230 V
Frequency: 50 - 60 Hz
Current: 9.2 A
Rated power: 2000W
Idle speed: 4100 rpm
Dial Diameter: 235mm
Dial Hole Diameter: 30mm
Maximum cutting capacity:
At 90°: 85 mm
At 45°: 60 mm
At 50°: 53 mm
Weight (EPTA): 6.7 kg
Dimensions (L x W x H): 380 mm x 255 mm x 287 mm
Safety class: II
Noise and vibration:
Sound pressure level error: 3 dB(A)
Sound Power Level Error: 3 dB(A)
Vibration level error: 1.5 m/s2
Sound pressure level: 100 dB(A)
Sound power level: 111 dB(A)
Vibration level: 2.5 m/s2 or less
Powerful motor 2000W
Designed for all work in soft and hard wood
Perfect for longitudinal and transverse cuts, recommended for sandwich panels
Strong steel cover and heavy-duty base
Steel cover with 5° opening angle in starting position
Flat motor housing for easy disc replacement
Adjustment of the cutting angle up to 50°
Ergonomic design of the lever to adjust the cutting depth
Properly placed fan exhaust keeps the cutting line clean
No kerf splitting wedge
Does not work with guide rail
Carbide cutting disc 235x30mm 20z (A-89866)
Side holder (152612-6)
Parallel guide (164367-1)
Suction connection (193068-4)
Flat wrench 13 (782016-4)
**
