GS1100-10HP-EU0102F 120W PoE 8xGigabit 2xFiber Uplilk Switch

Name: GS1100-10HP-EU0102F 120W PoE 8xGigabit 2xFiber Uplilk Switch
Brand: Zyxel
SKU: 1044180
Price: 158.74 EUR
Availability: InStock

€158.74

Shipping from warehouse: ⁨A3⁩

Estimated shipping: Wed, Nov 13 - Mon, Nov 18

14 days returnUnconditional return policy

Availability:: large quantity
Brand:: Zyxel
Product code:: GS1100-10HP-EU0102F / 4718937621187

Specification

10g support:	No
Ac input frequency:	50 - 60 Hz
Ac input voltage:	100 - 240 V
Auto mdi/mdi-x:	Yes
Basic switching rj-45 ethernet ports quantity:	8
Basic switching rj-45 ethernet ports type:	Gigabit Ethernet (10/100/1000)
Compliance certificates:	RoHS
Country of origin:	China
Dc input voltage:	54 V
Depth:	104 mm
Ethernet lan data rates:	100,1000 Mbit/s
Forwarding rate:	14.88 Mpps
Harmonized system (hs) code:	85176990
Heat dissipation:	89 BTU/h
Height:	27 mm
Jumbo frames:	9000
Jumbo frames support:	Yes
Led indicators:	Yes
Mac address table:	8000 entries
Master (outer) case gross weight:	13.7 kg
Master (outer) case height:	275 mm
Master (outer) case length:	558 mm
Master (outer) case width:	323 mm
Mean time between failures (mtbf):	1000070 h
Networking standards:	IEEE 802.3z, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3at, IEEE 802.3x, IEEE 802.3af, IEEE 802.3az
Operating relative humidity (h-h):	10 - 90%
Operating temperature (t-t):	0 - 50 °C
Package depth:	304 mm
Package height:	67 mm
Package weight:	1.97 kg
Package width:	228 mm
Packet buffer memory:	0.256 MB
Power connector:	DC-in jack
Power consumption (max):	156.1 W
Power over ethernet (poe):	Yes
Power over ethernet (poe) ports quantity:	8
Power source:	AC/DC
Power supply included:	Yes
Product colour:	Black
Products per master (outer) case:	8 pc(s)
Sfp module slots quantity:	2
Storage relative humidity (h-h):	10 - 95%
Storage temperature (t-t):	-40 - 70 °C
Sustainability certificates:	RoHS
Sustainability compliance:	Yes
Switch type:	Unmanaged
Switching capacity:	20 Gbit/s
Total power over ethernet (poe) budget:	130 W
Wall mountable:	Yes
Weight:	730 g
Width:	250 mm

Whisper quiet operation

The fanless design of the GS1100 ensures quiet operation in small and quiet office environments. The GS1100-10HP PoE model features an external power supply that eliminates the need for an additional fan to cool the unit, making it ideal for quiet PoE applications.

Energy Saving

The GS1100 is equipped with energy-efficient Ethernet (IEEE 802. 3az) that automatically detects network traffic and dynamically adjusts power consumption. Zyxel's green features also adjust power consumption by detecting link status and cable length and reducing operating costs.

PoE+ Support

The GS1100-10HP supports PoE+ (IEEE 802. 3at), which provides up to 30 watts per port and provides fully automatic support for compatible IP phones, video surveillance cameras or wireless access points.

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
