Technical data:
System: LXT 7.2V / LXT 10.8V / CXT 10.8V / CXT 12V Max / LXT 14.4V / LXT 18V
Voltage: 7.2V/10.8V/12V Max/14.4V/18V
Battery Type: Li-ion
Antenna System: DAB/FM: Flexible Antenna
FM frequency range: 87.5 - 108MHz
DAB/DAB+ frequency range: 174.928 - 239.200 MHz
DAB/DAB+ Channel lock: DAB (Band III) 5A-13F
Bluetooth:
Standard: 4.0
Profiles: A2DP, SCMS-T
Transmission Power: Power Class 2
Transmission range:
Optimally: maximum 10 m
Possible: 30 m
Supported codec: SBC, AAC
Maximum radio frequency power:
BT EDR: 3.12dBm
BT LE: 2.31dBm
Working Frequency: 2402MHz~2480MHz
Audio Input (AUX):
Number of entrances: 2
Standard: minijack 3.5 mm
Output power depending on battery type:
LXT 7.2V: 2x 0.6W
LXT 10.8V / CXT 10.8V - 12V Max: 2x 1.7W
LXT 14.4V: 2x 3.0W
LXT 18V: 2x 4.9W
Speakers: 2x diameter 89 mm (32 Ohm)
Works with batteries:
LXT 7.2V: BL7010, BL0715
LXT 10.8V: BL1013
CXT 10.8V - 12V Max: BL1015, BL1016, BL1020B, BL1021B, BL1040B, BL1041B
LXT 14.4V: BL1415, BL1415N, BL1430, BL1430B, BL1440, BL1450, BL1460B
LXT 18V: BL1815, BL1815N, BL1820, BL1820B, BL1830, BL1830B, BL1840, BL1840B, BL1850, BL1850B, BL1860B
Supported battery capacities: 1.0Ah / 1.3Ah / 1.5Ah / 2.0Ah / 3.0Ah / 4.0Ah / 5.0Ah / 6.0Ah
Dimensions:
With handle folded (L x W x H): 282 mm x 163 mm x 294 mm
With unfolded handle (L x W x H): 262 mm x 163 mm x 431 mm
Weight (EPTA): 4.3 - 4.9 kg
Approximate working time:
With LXT 7.2V battery:
1.0Ah: 5.0 h
1.5Ah: 7.5 h
With 10.8V LXT battery:
1.3Ah: 7.0 h
With CXT 10.8V - 12V Max battery:
1.5Ah: 8.5 h
2.0Ah: 11 h
4.0Ah: 21 h
With 14.4V LXT battery:
1.3Ah: 6.0 h
1.5Ah: 7.0 h
3.0Ah: 12 h
4.0Ah: 19 h
5.0Ah: 23 h
6.0Ah: 25 h
With LXT 18V battery:
1.3Ah: 6.5 h
1.5Ah: 7.5 h
2.0Ah: 10h
3.0Ah: 14 h
4.0Ah: 20 h
5.0Ah: 26 h
6.0Ah: 31 h
Equipped with bluetooth class 2 with a possible range of up to 30 m in good radio conditions (optimal range is 10 m)
Possibility to receive FM or DAB / DAB+ radio stations
DAB / DAB+ - Digital broadcasting technology
Maximum power output has been increased by using a new digital amplifier
Resistant to light rain (IP64 insulation class)
2-speaker stereo system
Rubberized handle adjustable by 90°
Backlit digital display
Possibility of power supply from two sources: power supply or battery
Equipped with a USB port for charging mobile devices
Thanks to the AUX input and bluetooth technology, it can be used as a stereo speaker when another sound source is connected
Does not work with Ni-Cd and Ni-Mh batteries and G-type Li-Ion batteries
AC Adapter 230V / DC12V
**
The device does not require batteries for operation, it can be powered from the power supply, which is included in the set.
The Micro USB connector is for software updates only.
No batteries or charger.
The photo has an illustrative function.
