The Darkflash APC1 PWM controller is responsible for controlling the operation of computer fans. It offers support for 14 lighting effects and motherboard compatibility. It has several ARGB and PWM ports.
The module provides control over the temperature and speed of the fans via the PMW/FG port. What's more, it also has 6 ARGB ports, 5 PWM ports and synchronization support with ASUS, MSI, GIGABYTE and ASROCK motherboards. In this way, you will merge lighting effects with other ARGB products.
The APC1 controller gives you the ability to synchronize lighting effects with an external signal. Simply use the RESET port to switch the signal reception to PC mode. Everything for your convenience! *Note* The device does not work with 12V/4 Pin ports.
Included with the controller you will also receive a remote control that will provide you with comfortable operation of the device. With its help, you can change the color and backlight mode or run APC1 synchronization with the motherboard.
- Controller
- RGB signal cable
- Remote control
| Producer | Darkflash |
|---|---|
| Model | APC1 |
Interface Compatible Motherboards | 5 V / 3 Pin ASUS, MSI, GIGABYTE, ASROCK |
| Ports | RESET MBPWM SYNC PWM/FG ARGB x 6 PWM x 5 |
