The device allows to transmit high definition signals to a TV equipped with HDMI connector via twisted-pair cable cat. 5, 5e, 6
EXTENDER TRANSMITTER HDMI-EX-150IR/TX-V4
€76.64
Shipping from warehouse: D4
Estimated shipping: Mon, Nov 25 - Tue, Nov 26
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Product code:
- HDMI-EX-150IR/TX-V4 / 5902887065101
Share this product:
Specification
| Current consumption: | 3 watts |
|---|---|
| Dimensions: | 97 x 94 x 24 mm |
| Hdcp: | 1.4 |
| Maximum transmission range: | 120 m @ 1080p - UTP cat. 6 100 m @ 1080p - UTP cat. 5e 80 m @ 1080p - UTP cat. 5 |
| Operating temperature: | 0 °C ... 60 °C |
| Power: | 5 V DC / 1 A - (power adapter included) |
| Protocols: | HDbitT |
| Scales: | 0.146 kg |
| Selected features: | IR carrier frequency : 20 ... 60 kHz Baudrate : 18 Mbps Protection : lightning, Surge protection, ESD |
| Standard hdmi: | 1.3 |
| Supported hdmi resolutions: | 1080p, 1080i, 720p, 576p, 576i, 480p, 480i |
| Type of device: | TRANSMITTER |
| Warranty: | 2 years |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
