Eaton Ellipse ECO 500 IEC Standby (Offline) 0.5 kVA 300 W 4 AC outlet s
€160.67
Shipping from warehouse: M7
Estimated shipping: Thu, Nov 28 - Mon, Dec 2
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Eaton
- Product code:
- EL500IEC / 3553340620539
Share this product:
Specification
| Ac outlet types: | C13 coupler |
|---|---|
| Ac outlets quantity: | 4 AC outlet(s) |
| Audible alarm modes: | Battery replacement |
| Audible alarm(s): | Yes |
| Automatic battery test: | Yes |
| Battery technology: | Sealed Lead Acid (VRLA) |
| Cold start: | Yes |
| Depth: | 235 mm |
| Emergency power off (epo): | No |
| Ethernet lan (rj-45) ports: | 1 |
| Form factor: | Tower |
| Harmonized system (hs) code: | 85078000 |
| Height: | 263 mm |
| Hot-swap battery: | No |
| Input connection type: | IEC |
| Input frequency: | 50/60 Hz |
| Input operation voltage (max): | 284 V |
| Input operation voltage (min): | 161 V |
| Led indicators: | Battery replacement |
| Modem (rj-11) ports: | 1 |
| Nominal input voltage: | 230 V |
| Nominal output voltage: | 220-240 V |
| Output operation voltage (max): | 240 V |
| Output operation voltage (min): | 220 V |
| Output power: | 300 W |
| Output power capacity: | 0.5 kVA |
| Overload protection: | Yes |
| Power plug: | C14 coupler |
| Product colour: | Black |
| Rack capacity: | 2U |
| Safety: | IEC 62040-1, IEC 60950-1, IEC 62040-2, CB Report, CE mark, IEC 61643-1 |
| Surge protection: | Yes |
| Surge protection features: | Modem, Network, Telephone, Fax |
| Typical backup time at half load: | 9 min |
| Ups topology: | Standby (Offline) |
| Weight: | 2.9 kg |
| Width: | 81 mm |
