The Eaton Ellipse ECO is a compact device designed to maintain power supply with built-in surge protection (IEC 61643-1 compliant). Provide complete protection for home computers and digital entertainment systems. Comfortable flat design makes it easy to install in any office environment. The device has data transmission line protection such as Ethernet, Internet and telephone lines.
EATON ELipse Eco EL500FR 500VA UPS
€113.40
Shipping from warehouse: A3
Estimated shipping: Tue, Dec 24 - Fri, Dec 27
14 days returnUnconditional return policy
- Availability:
- large quantity
- Brand:
- Eaton
- Product code:
- EL500FR / 3553340620515
Share this product:
Specification
Ac outlet types: | Type E |
---|---|
Ac outlets quantity: | 4 AC outlet(s) |
Apparent power (va): | 500 |
Architecture: | Offline |
Arrangement: | Tower |
Audible alarm: | Yes |
Audible alarm modes: | Battery replacement |
Audible alarm(s): | Yes |
Automatic battery test: | Yes |
Battery technology: | Sealed Lead Acid (VRLA) |
Battery type: | Lead acid (VRLA) |
Case: | Desktop, Tower |
Cold start: | Yes |
Communication connectors: | No |
Data line protection slots: | RJ-11 (modem/telephone), RJ-45 (LAN) |
Depth: | 235 mm |
Depth (cm): | 23.5 |
Emergency power off: | No |
Emergency power off (epo): | No |
Equipment: | Power cord |
Ethernet lan (rj-45) ports: | 1 |
Ethernet lan ports (rj-45) quantity: | 1 |
Form factor: | Tower |
Harmonized system (hs) code: | 85078000 |
Height: | 263 mm |
Height (cm): | 26.3 |
Hold time: | 9 minutes at 50% load |
Hot-swap battery: | No |
Hot-swappable batteries: | No |
Inbound connection type: | FR |
Input connection type: | FR |
Input frequency: | 50/60 Hz |
Input operating voltage (maximum): | 284 volts |
Input operating voltage (minimum): | 161 volts |
Input operation voltage (max): | 284 V |
Input operation voltage (min): | 161 V |
Input voltage (v): | 184 - 264 |
Kind: | Uninterruptible power supply |
Led indicators: | Battery replacement |
Leds: | Battery replacement |
Maximum configurable power: | 0.5 kVA |
Modem (rj-11) ports: | 1 |
Network ports: | 4x grounding pin socket (type E) with child resistant |
Nominal input voltage: | 230 V |
Nominal output voltage: | 220-240 V |
Nominal value of input voltage: | 230 volts |
Nominal value of output voltage: | 220-240 volts |
Number of power outlets: | 4 x AC connectors |
Other parameters: | 3 sockets with power backup; 1 socket with surge protection only, Battery replacement indicators: LED + audible alarm, Deep discharge protection, Surge arrester in accordance with IEC 61643-1, Battery type: Replaceable sealed lead-acid |
Output operating voltage (maximum): | 220 volts |
Output operating voltage (minimum): | 240 volts |
Output operation voltage (max): | 240 V |
Output operation voltage (min): | 220 V |
Output power: | 300 W |
Output power capacity: | 0.5 kVA |
Output voltage (v): | 220/230/240 |
Overload protection: | Yes |
Plug: | C14 panel |
Power (w): | 300 |
Power plug: | C14 coupler |
Product colour: | Black |
Product depth: | 235 mm |
Product height: | 263 mm |
Product weight: | 2.9 kg |
Product width: | 81 mm |
Protection against sudden voltage surge: | Yes |
Rack capacity: | 2U |
Real power: | 300 watts (Printing) |
Rj-11 modem ports: | 1 |
Safety: | IEC 62040-1, IEC 60950-1, IEC 62040-2, CB Report, CE mark, IEC 61643-1 |
Security measures applied: | Overvoltage, Resetting input fuse |
Surge protection: | Yes |
Surge protection features: | Network, Telephone, Fax, Modem |
Types of ac outputs: | Type E |
Typical backup time at half load: | 9 min |
Typical run-time at half load: | 9 mins |
Ups topology: | Standby (Offline) |
Ups topology: | Standby (Offline) |
Warranty: | 2 years |
Weight: | 2.9 kg |
Weight (kg): | 2.9 |
Width: | 81 mm |
Width (cm): | 8.1 |
