DeepCool PN850M power supply unit 850 W 20+4 pin ATX ATX Black
€137.27
Shipping from warehouse: A3
Estimated shipping: Thu, Nov 28 - Mon, Dec 2
14 days returnUnconditional return policy
- Availability:
- large quantity
- Brand:
- Deepcool
- Product code:
- R-PN850M-FC0B-EU / 6933412719564
Share this product:
Specification
| 80 plus certification: | 80 PLUS Gold |
|---|---|
| Ac input frequency: | 50/60 Hz |
| Ac input voltage: | 100 - 240 V |
| Atx power connector (20+4 pin): | Yes |
| Atx version: | 3.1 |
| Bearing technology: | FDB |
| Cable tie(s) included: | Yes |
| Cables included: | AC |
| Cabling type: | Fully-Modular |
| Combined power (-12v): | 3.6 W |
| Combined power (+12v): | 846 W |
| Combined power (+3.3v): | 110 W |
| Combined power (+5v): | 110 W |
| Combined power (+5vsb): | 15 W |
| Cooling type: | Active |
| Cpu power cable length: | 70 cm |
| Cpu power connector (4+4 pin): | Yes |
| Depth: | 140 mm |
| Efficiency: | 90% |
| Fan diameter: | 12 cm |
| Fan location: | Top |
| Height: | 86 mm |
| Hold time: | 16 ms |
| Input current: | 10 - 5 A |
| Max output current (-12v): | 0.3 A |
| Max output current (+12v): | 70.5 A |
| Max output current (+3.3v): | 20 A |
| Max output current (+5v): | 20 A |
| Max output current (+5vsb): | 3 A |
| Mean time between failures (mtbf): | 100000 h |
| Motherboard power cable length: | 55 cm |
| Motherboard power connector: | 20+4 pin ATX |
| Number of fans: | 1 fan(s) |
| Number of sata power connectors: | 8 |
| On/off switch: | Yes |
| Operating temperature (t-t): | 0 - 40 °C |
| Package type: | Box |
| Pci express power connectors (16-pin): | 1 |
| Pci express power connectors (6+2 pin): | 3 |
| Peripheral (molex) power cable length: | 850 mm |
| Peripheral (molex) power connectors (4-pin): | 2 |
| Power factor correction (pfc) type: | Active |
| Power good signal delay range: | 100 - 150 ms |
| Power protection features: | Short circuit, Over voltage, Surge & inrush protection (SIP), No load operation, Over power, Under voltage, Overheating, Surge protection |
| Power supply unit (psu) form factor: | ATX |
| Product colour: | Black |
| Purpose: | PC |
| Sata power cable length: | 750, 650 mm, 550, 450 |
| Sustainability certificates: | CE, CCC, Federal Communications Commission (FCC), ErP, Triman, EAC, RCM, RoHS, WEEE |
| Sustainability compliance: | Yes |
| Total power: | 850 W |
| Width: | 150 mm |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
