Technical data:
Cutting capacity at 0°: 60 x 123 mm
Cutting capacity at 45° (at an angle): 60 x 80 mm
Cutting capacity at 45° (diagonal): 43 x 123 mm
Angle Setting: 47°L / 47°P
Tilt Setting: 45°L/0°P
Tool dimensions (width x length x height): 500 x455 x325 mm
No-load rotation speed: 4.800 min-1
About the saw blade: 216 mm
About the dial hole: 30 mm
Weight: 10.1 kg
Nominal power: 1.300 W
Sound pressure level: 96 dB(A)
Sound power level: 106 dB(A)
Measurement error K: 3 dB
Noise level: The A-weighted noise level of the power tool is typically: Sound pressure level 96 dB(A) Sound power level 106 dB(A). Measurement error K = 3 dB.
Segments: Stationary power tools
Segment of mailing recipients:
- Wood
- Metal
Precise, repeatable, in the same order, thanks to
Portable slash with ergonomic handle for quick transport from one workplace to another
Practical while ensuring the possibility of making repetitive cuts and obtaining such elements
Precision laser smoothing precise cutting
Easy cleaning thanks to the ease of making the table available – all you need is a screw two screws
Stable table extension and durable support and next availability and more will provide support
1 Optiline Wood saw blade, 216 x 2.0/1.4 x 30 mm, 48
2 608 640 432
**
