Technical data:
System: LXT 18V
Voltage: 18V
Battery Type: Li-ion
Frequency of idling jumps: 800 - 3500 sk/min
Stroke length 26 mm
Bevel angle: 45°
Maximum cutting depth:
Wood: 135 mm
Mild steel: 10 mm
Aluminum: 20 mm
Dimensions (L x W x H): 266 mm x 77 mm x 208 mm
Weight (EPTA): 2.4 - 2.7 kg
Noise and vibration:
Sound pressure level error: 3 dB(A)
Sound Power Level Error: 3 dB(A)
Vibration level error: 1.5 m/s2
Sound pressure level: 77 dB(A)
Sound power level: 80 dB(A)
Vibration level when cutting plates: 7.0 m/s2
Vibration level when cutting metal sheets: 3.5 m/s2
BLDC - brushless DC motor
Switch lock function
Tool-free saw blade replacement
Accidental start lock
Soft start
New improved tip for connecting the suction hose
"Soft No Load" function automatically reduces engine speed when idling to dampen vibrations of the machine body
3-step undercutting adjustment + straight cutting
Speed control knob
Tool-free blade change
Trigger switch with lock button
Chip blowing system from the cutting line
Ergonomic soft grip
Rigid base plate made of pressurized aluminum tilted in both directions by 45°
Presetting the frequency of strokes with the knob
Built-in LED lighting
Does not work with BL1811G, BL1813G, BL1815G batteries (without electronics) and BL1815 battery (18V / 1.3Ah)
Saw blade set
Connection for suction device: 126331-0
Allen Key 4: 783202-0
**
Without case, battery and charger
