Voltage booster converter module PZU-3509-W4 converts the input voltage to 5V ... 35VDC
CONVERTER MODULE PZU-3509-W4 DC/DC
€13.33
Shipping from warehouse: D4
Estimated shipping: Tue, Nov 26 - Fri, Nov 29
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Delta
- Product code:
- PZU-3509-W4 / 5902887048401
Share this product:
Specification
| Destiny:: | to power cameras to power cameras with thermostat |
|---|---|
| Dimensions:: | 120 x 90 x 36 mm |
| Manufacturer / brand:: | DELTA |
| Minimum voltage difference between output and output:: | 0 volts |
| Number of inputs:: | 2 - compact |
| Number of outputs:: | 2 - compact |
| Output voltage adjustment:: | Adjustable with a precision multiturn potentiometer (27 rpm) |
| Output voltage:: | 5 ... 35 VDC |
| Output:: | 2 A (max. max. |
| Power:: | 24 W (max) |
| Scales:: | 0.09 kg |
| Security:: | Short-circuit Thermal Reverse Connection |
| Selected features:: | LED Signaling - Input Voltage, Output Voltage |
| Supply voltage:: | 5 ... 32 VDC |
| Type:: | Voltage boosting, DC/DC |
| Warranty:: | 3 years |
