Technical data:
Power: 1600W
Max. Cutting depth at 90° (mm): 66
No-load speed (rpm): 5,000
Angle adjustment for bevel cutting (°): 45
Dial Hole Diameter (mm): 16
Cutting Disc Diameter (mm): 190
Weight (kg): 3.7
Noise level error (dB(A)): 3.0
Sound pressure level error (dB(A)): 3.0
Sound pressure level (Lpa)(dB(A)): 96.0
Sound Power Level (LW)(dB(A)): 107.0
Vibration level error when cutting in wood (m/s2): 1.5
Vibration level when cutting in wood (m/s2): 4.0
190 mm blade with 24 carbide teeth for exceptional cutting quality and increased productivity
A powerful 1600W motor drives the tool up to 5000 rpm. ensuring fast and effective cutting of wood
Impressive cutting depth of 66 mm at 90° and 55 mm at 45°
Up to 30% more compact and 20% lighter design for comfortable and repeatable cuts
Integrated laser for more precise operation
1 carbide disc (24 teeth)
Parallel guide
Key
Suitcase
**
Power: 1600W
Max. Cutting depth at 90° (mm): 66
No-load speed (rpm): 5,000
Angle adjustment for bevel cutting (°): 45
Dial Hole Diameter (mm): 16
Cutting Disc Diameter (mm): 190
Weight (kg): 3.7
Noise level error (dB(A)): 3.0
Sound pressure level error (dB(A)): 3.0
Sound pressure level (Lpa)(dB(A)): 96.0
Sound Power Level (LW)(dB(A)): 107.0
Vibration level error when cutting in wood (m/s2): 1.5
Vibration level when cutting in wood (m/s2): 4.0
190 mm blade with 24 carbide teeth for exceptional cutting quality and increased productivity
A powerful 1600W motor drives the tool up to 5000 rpm. ensuring fast and effective cutting of wood
Impressive cutting depth of 66 mm at 90° and 55 mm at 45°
Up to 30% more compact and 20% lighter design for comfortable and repeatable cuts
Integrated laser for more precise operation
1 carbide disc (24 teeth)
Parallel guide
Key
Suitcase
**
