CAMERA AHD, HD-CVI, HD-TVI, CVBS OUTDOOR SPEED DOME OMEGA-PTZ-52H4-4 - 5 Mpx 2.8 ... 12 mm

€132.12

Shipping from warehouse: ⁨D4⁩

Estimated shipping: Mon, Nov 25 - Tue, Nov 26

14 days returnUnconditional return policy

Availability:: moderate quantity
Product code:: OMEGA-PTZ-52H4-4 / 5902887056628

Specification

Adjustable traffic routes:	8
Case:	Speed Dome, Plastic
Colour:	white
Control:	Using the RS-485 interfaceDefault address : 1, 2400 bit/s
Digital zoom:	x 16
Dimensions:	Ø 110 x 100 mm
Horizontal rotation range:	0 ° ... 350 ° - The rotation of the head is limited by the limit switch
Ir illuminator range:	60 m
Number of presets:	220
Objective:	2.8 ... 12 mm - Motozoom
Operating temperature:	-40 °C ... 60 °C
Optical zoom:	x 4
Park action:	Invoking a preset position after a specified period of inactivity
Power:	12 volts DC / 860 mA
Power consumption:	≤ 10.3 watts
Protocols:	Pelco-D, Pelco-P (auto detection)
Resolution:	AHD / HD-TVI: 2592 x 1944 px - 5 Mpx @ 15, 20 fps AHD / HD-CVI / HD-TVI: 2560 x 1440 px - 4 Mpx @ 25 fps CVBS: 960 x 576 px - 960H
Rotational speed (manual control):	20 °/s (horizontal) .25 °/s (vertical)
Rotational speed at presets:	25 °/s (horizontal)20 °/s (vertical)
S/n ratio (s/n):	> 50 dB
Scales:	0.57 kg
Sealing:	IP67
Selected features:	3D-DNR - Digital Image Noise Reduction AGC - Automatic image gain adjustment Auto white balance Auto white balance ICR - Mechanical IR filter Sharpness - Sharpness of image contours
Sensor size:	5 MP
Standard:	AHD, HD-CVI, HD-TVI, CVBS
Supported languages:	English
Transducer:	1/2.9" Sony CMOS
Vertical rotation range:	0 ° ... 70 °
Video output:	AHD / HD-CVI / HD-TVI / CVBS, 1 Vpp 75 Ω
Viewing angle:	91 ° ... 28 ° (manufacturer's data) 70 ° ... 29° (our tests)
Warranty:	2 years

Very small external PTZ camera with motozoom lens

The AHD / HD-CVI / HD-TVI interface allows transmission of analog video signal via coaxial cable at max. 8 Mpx (4K UHD)There are no delays during transmission and the original, high image quality is preserved

The range of the illuminator given by the manufacturer depends on the environmental conditions (transparency of air, environment, color of walls, i.e. the so-called scene reflectance)The camera meets IP66 protection class

Remark! Changing the camera ID address is done by calling two presets in succession: first the preset 97, and then the preset with the number corresponding to the new address of the camera ID

In order to change the standard via RS-485 (using the keyboard or from the recorder) it is necessary to:
2x call preset 137 to change to AHD
2x call preset 138 to change to TVI
2x call preset 139 to change to CVI
2x call preset 140 to change to CVBS

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
