| Battery charging current:: | 1 A |
|---|---|
| Battery space:: | 12V/18Ah |
| Control of power supply operation:: | Signaling the presence of mains power Signaling the presence of output voltage |
| Current efficiency (total):: | 5 A |
| Dimensions:: | 288 x 286 x 90 mm |
| Input voltage:: | 85 ... 264 VAC |
| Max. battery dimensions:: | 260 x 170 x 75 mm |
| Number of outputs:: | 1 |
| Output voltage:: | 13.8 V DC (mains mode) 10.5 V ... 13.8 V DC (battery mode) |
| Power supply type:: | Pulse |
| Power:: | 74.5 watts |
| Scales:: | 1.84 kg |
| Security:: | Short-circuit Overload Overvoltage Before over-discharge |
| Warranty:: | 2 years |
The buffer power supply is designed to power alarm control panels, sensors, code locks, cameras, keypads, intercoms and other devices included in the alarm system
Remark! If the power supply is designed for continuous operation (24H), the rated current of the power supply should not exceed 80% of the maximum current
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
