BUFFER POWER SUPPLY AD-55A

€41.83
Shipping from warehouse: ⁨D4⁩
Estimated shipping: Fri, Nov 29 - Mon, Dec 2
14 days returnUnconditional return policy
Availability:
moderate quantity
Brand:
MEAN WELL
Product code:
AD-55A / 5901643192020

Specification

Battery charging current:0.23 A
Dimensions:160 x 97 x 38 mm
Efficiency:71 %
Emi issued and conducted:Complies with EN55022 (CISPR22) Class B
Ems resistance:Complies with EN61000-4-2, 3, 4, 5, 6, 8, 11, ENV50204, EN55024, EN61000-6-1
Harmonic:Complies with EN61000-3-2,-3
Number of outputs:1 pc
Operating temperature / relative humidity:-10 °C ... 50 °C / 20 % ... 90 %
Output voltage:13.8 VDC
Output voltage adjustment:12  ... 14.5 volts
Power supply:50 watts (Printing)
Power supply current efficiency:3.5 A
Scales:0.45 kg
Security:Surge Protection Overload Protection
Standards met:UL60950-1, TUV EN60950-1
Supply voltage:100  ... 240 VAC
Type of power supply:Pulse
Warranty:2 years

The buffer power supply is designed to power alarm control panels, sensors, code locks, cameras, keypads, intercoms and other devices included in the alarm system

Remark! If the power supply is designed for continuous operation (24H), the rated current of the power supply should not exceed 80% of the maximum currentParticular attention should be paid to the proper cooling of the power supply during operation!

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
