Biostar Z590MHP Intel Z590 LGA 1200 (Socket H5) micro ATX
This product is not available
- Availability:
- expected delivery
- Brand:
- Biostar
- Product code:
- Z590MHP / 4712960687769
Share this product:
Specification
| Atx power connector (24-pin): | Yes |
|---|---|
| Audio chip: | Realtek ALC897 |
| Audio output channels: | 7.1 channels |
| Bios type: | UEFI |
| Cables included: | SATA |
| Clear cmos jumper: | Yes |
| Compatible processor series: | Intel® Pentium®, Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i3 |
| Cpu fan connector: | Yes |
| Depth: | 226 mm |
| Directx version: | 12.0 |
| Drivers included: | Yes |
| Ecc сompatibility: | Non-ECC |
| Eps power connector (8-pin): | Yes |
| Ethernet interface type: | Gigabit Ethernet, Fast Ethernet |
| Ethernet lan: | Yes |
| Ethernet lan (rj-45) ports: | 1 |
| Front panel audio connector: | Yes |
| Front panel connector: | Yes |
| Hdcp: | Yes |
| Hdmi ports quantity: | 1 |
| Hdmi version: | 1.4 |
| Lan controller: | Intel® I219-V |
| Maximum internal memory: | 64 GB |
| Maximum number of smp processors: | 1 |
| Memory channels: | Dual-channel |
| Memory slots type: | DIMM |
| Motherboard chipset: | Intel Z590 |
| Motherboard chipset family: | Intel |
| Motherboard form factor: | micro ATX |
| Number of chassis fan connectors: | 2 |
| Number of com connectors: | 1 |
| Number of m.2 (m) slots: | 1 |
| Number of memory slots: | 2 |
| Number of sata iii connectors: | 4 |
| Pc health monitoring: | Voltage, Fan, CPU, Temperature |
| Pci express x1 (gen 3.x) slots: | 2 |
| Pci express x16 (gen 3.x) slots: | 1 |
| Power fan connector: | Yes |
| Processor manufacturer: | Intel |
| Processor socket: | LGA 1200 (Socket H5) |
| Ps/2 ports quantity: | 2 |
| Raid levels: | 1, 10, 5, 0 |
| Raid support: | Yes |
| Supported memory clock speeds: | 3200 MHz, 2666, 4000, 3733, 2133, 3800, 3866, 2400, 2800, 2933, 3600 MHz |
| Supported memory types: | DDR4-SDRAM |
| Supported storage drive interfaces: | M.2, SATA III |
| Supported storage drive types: | HDD & SSD |
| Usb 2.0 connectors: | 1 |
| Usb 2.0 ports quantity: | 4 |
| Usb 3.2 gen 1 (3.1 gen 1) connectors: | 1 |
| Usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity: | 2 |
| Vga (d-sub) ports quantity: | 1 |
| Wi-fi: | No |
| Width: | 185 mm |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
