Biostar H510MHP 2.0 motherboard Intel H510 LGA 1200 (Socket H5) micro ATX
€71.30
Shipping from warehouse: A3
Estimated shipping: Mon, Sep 23 - Thu, Sep 26
14 days returnUnconditional return policy
- Availability:
- large quantity
- Brand:
- Biostar
- Product code:
- H510MHP 2.0 / 4712960687011
Share this product:
Specification
| Atx power connector (24-pin): | Yes |
|---|---|
| Audio chip: | Realtek ALC897 |
| Audio output channels: | 7.1 channels |
| Bios type: | UEFI |
| Cables included: | SATA |
| Clear cmos jumper: | Yes |
| Compatible processor series: | Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i3, Intel® Pentium®, Intel® Core™ i7, Intel® Core™ i9 |
| Cpu fan connector: | Yes |
| Depth: | 226 mm |
| Directx version: | 12.0 |
| Drivers included: | Yes |
| Eps power connector (8-pin): | Yes |
| Ethernet interface type: | Gigabit Ethernet |
| Ethernet lan: | Yes |
| Ethernet lan (rj-45) ports: | 1 |
| Front panel audio connector: | Yes |
| Front panel connector: | Yes |
| Hdcp: | Yes |
| Hdmi ports quantity: | 1 |
| Headphone outputs: | 1 |
| Lan controller: | Intel® I219-V |
| Maximum internal memory: | 64 GB |
| Memory slots type: | DIMM |
| Motherboard chipset: | Intel H510 |
| Motherboard chipset family: | Intel |
| Motherboard form factor: | micro ATX |
| Number of com connectors: | 1 |
| Number of m.2 (m) slots: | 1 |
| Number of memory slots: | 2 |
| Number of sata iii connectors: | 4 |
| Pci express x1 (gen 3.x) slots: | 2 |
| Pci express x16 (gen 3.x) slots: | 1 |
| Processor manufacturer: | Intel |
| Processor socket: | LGA 1200 (Socket H5) |
| Ps/2 ports quantity: | 2 |
| Supported memory clock speeds: | 2400, 3200 MHz, 2666, 1866, 2933 MHz, 2133 |
| Supported memory module capacities: | 16GB, 32GB, 8GB, 4GB |
| Supported memory types: | DDR4-SDRAM |
| Supported storage drive interfaces: | M.2, PCI Express 3.0, SATA III |
| Usb 2.0 connectors: | 1 |
| Usb 2.0 ports quantity: | 4 |
| Usb 3.2 gen 1 (3.1 gen 1) connectors: | 1 |
| Usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity: | 2 |
| User guide: | Yes |
| Vga (d-sub) ports quantity: | 1 |
| Wi-fi: | No |
| Width: | 185 mm |
| Windows operating systems supported: | Windows 10 x64, Windows 11 x64 |
