ATEN DisplayPort HDBaseT-Lite Extender 4K/40m;1080p/70m
€424.55
Shipping from warehouse: E12
Estimated shipping: Tue, Dec 24 - Fri, Dec 27
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- ATEN
- Product code:
- VE901-AT-G / 4719264645204
Share this product:
Specification
| Ac adapter included: | Yes |
|---|---|
| Bandwidth: | 10.2 Gbit/s, 297 MHz |
| Cable types supported: | Cat6, Cat5e, Cat6a |
| Connectivity technology: | Wired |
| Dc-in jack: | Yes |
| Displayports in: | 1 |
| Displayports out: | 1 |
| Hdbaset certified: | Yes |
| Hdbaset port: | Yes |
| Hdcp: | Yes |
| Hdcp version: | 1.4 |
| Impedance: | 100 Ω |
| Led indicators: | Yes |
| Manual: | Yes |
| Master (outer) case gross weight: | 4.85 kg |
| Master (outer) case height: | 175 mm |
| Master (outer) case length: | 325 mm |
| Master (outer) case net weight: | 3.75 kg |
| Master (outer) case width: | 250 mm |
| Material: | Metal |
| Maximum resolution: | 4096 x 2160 pixels |
| Maximum transfer distance: | 70 m |
| Operating relative humidity (h-h): | 0 - 80% |
| Operating temperature (t-t): | 0 - 40 °C |
| Operating voltage (receiver): | 5 V |
| Operating voltage (transmitter): | 5 V |
| Package depth: | 239 mm |
| Package height: | 160 mm |
| Package weight: | 855 g |
| Package width: | 59 mm |
| Plug and play: | Yes |
| Power consumption (rx): | 5.72 W |
| Power consumption (tx): | 2.84 W |
| Product colour: | Black |
| Products per master (outer) case: | 5 pc(s) |
| Rack mounting: | Yes |
| Receiver dimensions (wxdxh): | 94.2 x 66 x 29 mm |
| Receiver weight: | 270 g |
| Rj-45 input ports: | 1 |
| Rj-45 output ports: | 1 |
| Storage relative humidity (h-h): | 0 - 80% |
| Storage temperature (t-t): | -20 - 60 °C |
| Supported graphics resolutions: | 4096 x 2160, 3840 x 2160 |
| Supported video modes: | 1080p |
| Transmitter dimensions (wxdxh): | 94.2 x 66 x 29 mm |
| Transmitter weight: | 240 g |
| Type: | AV transmitter & receiver |
| Weight: | 750 g |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
