ASUS TUF Gaming B760-Plus WIFI Intel B760 LGA 1700 ATX

Name: ASUS TUF Gaming B760-Plus WIFI Intel B760 LGA 1700 ATX
Brand: Asus
SKU: 1822469
Price: 189.63 EUR
Availability: InStock

€189.63

Shipping from warehouse: ⁨A3⁩

Estimated shipping: Mon, Apr 7 - Thu, Apr 10

14 days returnUnconditional return policy

Availability:: large quantity
Brand:
Product code:: 90MB1ER0-M1EAY0 / 4711387095119

Specification

12v power connector:	Yes
Atx power connector (24-pin):	Yes
Audio output channels:	7.1 channels
Bios type:	UEFI AMI
Bluetooth:	Yes
Bluetooth version:	5.2
Cables included:	SATA
Compatible processor series:	Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7
Cooling type:	Passive
Cpu fan connector:	Yes
Depth:	244 mm
Displayport version:	1.4
Displayports quantity:	1
Eps power connector (8-pin):	Yes
Ethernet interface type:	2.5 Gigabit Ethernet
Ethernet lan:	Yes
Ethernet lan (rj-45) ports:	1
Front panel audio connector:	Yes
Front panel connector:	Yes
Hdmi ports quantity:	1
Hdmi version:	2.1
Headphone outputs:	1
Line-in:	Yes
Maximum internal memory:	128 GB
Maximum number of smp processors:	1
Memory channels:	Dual-channel
Memory slots type:	DIMM
Motherboard chipset:	Intel B760
Motherboard chipset family:	Intel
Motherboard form factor:	ATX
Number of chassis fan connectors:	3
Number of com connectors:	1
Number of hdds supported:	4
Number of m.2 (m) slots:	3
Number of memory slots:	4
Number of sata iii connectors:	4
Number of storage drives supported:	7
Package depth:	266 mm
Package height:	53 mm
Package weight:	1.16 kg
Package width:	328 mm
Parallel processing technology support:	Not supported
Pci express x1 (gen 3.x) slots:	2
Pci express x16 (gen 4.x) slots:	1
Pci express x16 (gen 5.x) slots:	1
Peripheral (molex) power connectors (4-pin):	1
Power source type:	ATX
Processor manufacturer:	Intel
Processor socket:	LGA 1700
Raid levels:	10, 1, 0, 5
Raid support:	Yes
Rgb led pin header:	Yes
S/pdif out connector:	Yes
Supported memory clock speed (max):	5066 MHz
Supported memory types:	DDR5-SDRAM
Supported processor sockets:	LGA 1700
Supported storage drive interfaces:	M.2, PCI Express 3.0, PCI Express 5.0, SATA III
Supported storage drive types:	HDD & SSD
Thunderbolt headers:	1
Top wi-fi standard:	Wi-Fi 6E (802.11ax)
Tpm connector:	Yes
Unbuffered memory:	Yes
Usb 2.0 connectors:	2
Usb 2.0 ports quantity:	2
Usb 3.2 gen 1 (3.1 gen 1) connectors:	2
Usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity:	1
Usb 3.2 gen 2 (3.1 gen 2) type-a ports quantity:	2
Usb 3.2 gen 2x2 type-c ports quantity:	1
Vga (d-sub) ports quantity:	1
Wi-fi:	Yes
Wi-fi standards:	802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Width:	305 mm
Windows operating systems supported:	Windows 10, Windows 11

TUF Gaming B760-Plus Wi-Fi

TUF Gaming B760-Plus WiFi takes all the essential elements of the latest Intel processors and combines them with gaming-ready features and proven durability. Designed with military-grade components, an enhanced power solution and a versatile cooling system, this motherboard exceeds expectations, offering solid performance for gaming marathons. TUF Gaming motherboards also undergo rigorous durability testing to make sure they can handle conditions where other boards may fail. Aesthetically, this model features an embossed nameplate and geometric design elements that reflect the reliability and stability that define the TUF Gaming series.
