ASUS TUF GAMING B760-PLUS WIFI D4 Intel B760 LGA 1700 ATX

Name: ASUS TUF GAMING B760-PLUS WIFI D4 Intel B760 LGA 1700 ATX
Brand: Asus
SKU: 1211034
Price: 756.69 PLN
Availability: InStock

PLN 756.69

Shipping from warehouse: ⁨M7⁩

Estimated shipping: Thu, Apr 3 - Mon, Apr 7

14 days returnUnconditional return policy

Availability:: large quantity
Brand:
Product code:: 90MB1DF0-M0EAY0 / 4711387009499

Specification

12v power connector:	Yes
Atx power connector (24-pin):	Yes
Audio output channels:	7.1 channels
Bios type:	UEFI AMI
Bluetooth:	Yes
Bluetooth version:	5.2
Cables included:	SATA
Compatible processor series:	Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®
Cooling type:	Passive
Cpu fan connector:	Yes
Depth:	244 mm
Displayport version:	1.4
Displayports quantity:	1
Ecc сompatibility:	Non-ECC
Eps power connector (8-pin):	Yes
Ethernet interface type:	2.5 Gigabit Ethernet
Ethernet lan:	Yes
Ethernet lan (rj-45) ports:	1
Front panel audio connector:	Yes
Front panel connector:	Yes
Hdmi ports quantity:	1
Hdmi version:	2.1
Headphone outputs:	1
Line-in:	Yes
Maximum internal memory:	192 GB
Maximum number of smp processors:	1
Memory channels:	Dual-channel
Memory slots type:	DIMM
Microphone in:	Yes
Motherboard chipset:	Intel B760
Motherboard chipset family:	Intel
Motherboard form factor:	ATX
Number of chassis fan connectors:	4
Number of com connectors:	1
Number of hdds supported:	4
Number of m.2 (m) slots:	3
Number of memory slots:	4
Number of sata iii connectors:	4
Number of storage drives supported:	7
On-board graphics card:	No
Package depth:	76 mm
Package height:	266 mm
Package weight:	1.98 kg
Package width:	331 mm
Parallel processing technology support:	Not supported
Pci express x1 (gen 3.x) slots:	2
Pci express x16 (gen 3.x) slots:	1
Pci express x16 (gen 5.x) slots:	1
Peripheral (molex) power connectors (4-pin):	1
Power source type:	ATX
Processor manufacturer:	Intel
Processor socket:	LGA 1700
Product colour:	Black
Raid levels:	1, 5, 10, 0
Raid support:	Yes
Rgb led pin header:	Yes
S/pdif out port:	Yes
Supported memory types:	DDR4-SDRAM
Supported processor sockets:	LGA 1700
Supported storage drive interfaces:	M.2, SATA III
Supported storage drive types:	HDD & SSD
Thunderbolt headers:	1
Top wi-fi standard:	Wi-Fi 6 (802.11ax)
Unbuffered memory:	Yes
Usb 2.0 connectors:	2
Usb 2.0 ports quantity:	1
Usb 3.2 gen 1 (3.1 gen 1) connectors:	1
Usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity:	3
Usb 3.2 gen 2 (3.1 gen 2) connectors:	1
Usb 3.2 gen 2 (3.1 gen 2) type-a ports quantity:	1
Usb 3.2 gen 2x2 type-c ports quantity:	1
User guide:	Yes
Wi-fi:	Yes
Wi-fi standards:	802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11b
Width:	305 mm
Wifi-ap antenna jack:	2
Windows operating systems supported:	Windows 11, Windows 10

TUF Gaming B760-PLUS WIFI D4

TUF GAMING B760-PLUS WIFI D4 takes all the essential elements of the latest Intel processors and combines them with gaming-ready features and proven durability. Designed with military-grade components, an improved power solution, and a comprehensive cooling system, this motherboard exceeds expectations by offering solid performance for marathon gaming sessions. TUF GAMING motherboards also undergo rigorous durability testing to ensure they can handle conditions where others may fail. Aesthetically, this model features an embossed nameplate and geometric design elements that reflect the reliability and stability that define the TUF GAMING series.

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
