ASUS ROG STRIX Z790-A GAMING WIFI D4 Intel Z790 LGA 1700 ATX

€406.36
Shipping from warehouse: ⁨A3⁩
Estimated shipping: Fri, Nov 15 - Mon, Nov 18
14 days returnUnconditional return policy
Availability:
moderate quantity
Brand:
Asus
Product code:
90MB1CN0-M0EAY0 / 4711081941033

Specification

12v power connector:Yes
Atx power connector (24-pin):Yes
Audio chip:Realtek ALC4080
Audio output channels:7.1 channels
Back-to-bios button:Yes
Bios type:UEFI AMI
Bluetooth:Yes
Bluetooth version:5.3
Cables included:SATA
Clear cmos button:Yes
Compatible processor series:Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
Cpu fan connector:Yes
Depth:244 mm
Displayport version:1.4
Displayports quantity:1
Drivers included:Yes
Ecc сompatibility:Non-ECC
Eps power connector (8-pin):Yes
Ethernet interface type:2.5 Gigabit Ethernet
Ethernet lan:Yes
Ethernet lan (rj-45) ports:1
Front panel audio connector:Yes
Hdmi ports quantity:1
Hdmi version:2.1
Headphone outputs:1
Line-in:Yes
Maximum internal memory:128 GB
Memory channels:Dual-channel
Memory slots type:DIMM
Microphone in:Yes
Motherboard chipset:Intel Z790
Motherboard chipset family:Intel
Motherboard form factor:ATX
Number of chassis fan connectors:5
Number of m.2 (m) slots:4
Number of memory slots:4
Number of sata iii connectors:4
Package depth:293 mm
Package height:290 mm
Package width:368 mm
Parallel processing technology support:Not supported
Pci express x1 (gen 3.x) slots:1
Pci express x16 (gen 4.x) slots:2
Pci express x16 (gen 5.x) slots:1
Power source type:ATX
Processor manufacturer:AMD
Processor socket:LGA 1700
Raid levels:10, 1, 0, 5
Raid support:Yes
Rgb led pin header:Yes
S/pdif out port:Yes
Supported memory clock speed (max):5333 MHz
Supported memory clock speeds:3000, 5333 MHz, 4600 MHz, 3600 MHz, 5133, 4700 MHz, 5066, 3466, 4500, 3733, 4400, 5000, 3400, 3866, 4133, 4000, 4800, 3200 MHz, 4266, 3333
Supported memory types:DDR4-SDRAM
Supported processor sockets:LGA 1700
Supported storage drive interfaces:M.2, SATA III
Supported storage drive types:HDD & SSD
Thunderbolt headers:1
Top wi-fi standard:Wi-Fi 6E (802.11ax)
Unbuffered memory:Yes
Usb 2.0 connectors:2
Usb 2.0 ports quantity:2
Usb 3.2 gen 1 (3.1 gen 1) connectors:1
Usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity:4
Usb 3.2 gen 2 (3.1 gen 2) connectors:1
Usb 3.2 gen 2 (3.1 gen 2) type-a ports quantity:2
Usb 3.2 gen 2 (3.1 gen 2) type-c ports quantity:1
Usb 3.2 gen 2x2 type-c ports quantity:1
User guide:Yes
Wi-fi:Yes
Wi-fi standards:802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), 802.11b
Width:305 mm
Wifi-ap antenna jack:2
Windows operating systems supported:Windows 11, Windows 10
Gwarancja:
  • Gniazdo Intel LGA 1700: gotowy do pracy z procesorami Intel Core 13. generacji oraz procesorami Intel Core, Pentium Gold i Celeron 12. generacji
  • Kompleksowa obsługa M. 2: jedno gniazdo PCIe 4. 0 M. 2 z radiatorem i płytą tylną oraz trzy gniazda PCIe 4. 0 M. 2 z radiatorami
  • Różnorodna łączność: tylne złącze I/O USB 3. 2 Gen 2x2 Typ-C i dodatkowe złącze panelu przedniego z PD 3. 0 do 30W, porty USB 3. 2 Gen 2 i Gen 1, PCIe 5. 0 x16 SafeSlot, HDMI 2. 1 i DisplayPortTM 1. 4
  • Sieć o wysokiej wydajności: Wi-Fi 6E (802. 11ax) i Intel 2,5 Gb Ethernet z ASUS LANGuard
  • Wciągający dźwięk do gier: ALC4080 ze wzmacniaczem Savitech SV3H712 wraz z DTS Sound Unbound i Sonic Studio III

ROG STRIX Z790-A GAMING WIFI D4

Intel Z790 Chipset

13 i 12 generacji procesory Intel

  • Gniazdo M. 2_1 (Key M), typ 2242/2260/2280/22,110 (obsługuje tryb PCIe 4. 0 x4)

Chipset Intel Z790

  • Gniazdo M. 2_2 (Key M), typ 2242/2260/2280 (obsługuje tryb PCIe 4. 0 x4)
  • Gniazdo M. 2_3 (Key M), typ 2242/2260/2280/22,110 (obsługuje tryb PCIe 4. 0 x4)
  • Gniazdo M. 2_4 (Key M), typ 2242/2260/2280 (obsługuje tryby PCIe 4. 0 x4 i SATA)
  • 4 porty SATA 6 Gb/s

* Technologia Intel Rapid Storage obsługuje PCIe RAID 0/1. 5. 10 i SATA RAID 0/1. 5. 10.

  • 1 x DisplayPort**
  • 1 x złącze HDMI***

** Obsługa maks. 8K@60Hz zgodnie z DisplayPort 1. 4.

*** Obsługa 4K @ 60Hz zgodnie z HDMI 2. 1.

ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080

  • ASUS LANGuard
  • Wi-Fi 6E
  • 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
  • Obsługuje pasmo częstotliwości 2,4/5/6GHz*
  • Bluetooth v5.3**

* Regulacje dotyczące WiFi 6E 6GHz mogą się różnić w zależności od kraju.

256 Mb Flash ROM, UEFI AMI BIOS

30.5 cm x 24.4 cm

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
