Asrock Z790 Pro RS Intel Z790 LGA 1700 ATX

Name: Asrock Z790 Pro RS Intel Z790 LGA 1700 ATX
Brand: ASRock
SKU: 836902
Price: 233.87 EUR
Availability: InStock

€233.87

Shipping from warehouse: ⁨M7⁩

Estimated shipping: Mon, Sep 23 - Wed, Sep 25

14 days returnUnconditional return policy

Availability:: large quantity
Brand:: ASRock
Product code:: Z790 Pro RS / 4710483940767

Specification

Atx power connector (24-pin):	Yes
Audio chip:	Realtek ALC897
Audio output channels:	7.1 channels
Bios type:	UEFI AMI
Compatible processor series:	Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i5
Cpu fan connector:	Yes
Depth:	244 mm
Displayport version:	1.4
Displayports quantity:	1
Ethernet interface type:	2.5 Gigabit Ethernet
Ethernet lan:	Yes
Ethernet lan (rj-45) ports:	1
Front panel audio connector:	Yes
Hdmi ports quantity:	1
Headphone outputs:	1
Lan controller:	Dragon RTL8125BG
Line-in:	Yes
Maximum internal memory:	128 GB
Maximum number of smp processors:	1
Memory channels:	Dual-channel
Memory slots type:	DIMM
Motherboard chipset:	Intel Z790
Motherboard chipset family:	Intel
Motherboard form factor:	ATX
Number of m.2 (m) slots:	1
Number of memory slots:	4
Number of sata iii connectors:	8
Pci express x1 (gen 3.x) slots:	2
Pci express x16 (gen 4.x) slots:	1
Pci express x16 (gen 5.x) slots:	1
Processor manufacturer:	Intel
Processor socket:	LGA 1700
Ps/2 ports quantity:	1
Raid levels:	1, 10, 5, 0
Raid support:	Yes
Rgb led pin header:	Yes
Supported memory types:	DDR5-SDRAM
Supported storage drive interfaces:	M.2, SATA III
Supported storage drive types:	HDD & SSD
Thunderbolt headers:	1
Tpm connector:	Yes
Unbuffered memory:	Yes
Usb 2.0 connectors:	2
Usb 2.0 ports quantity:	4
Usb 3.2 gen 1 (3.1 gen 1) connectors:	2
Usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity:	2
Usb 3.2 gen 2 (3.1 gen 2) connectors:	1
Usb 3.2 gen 2 (3.1 gen 2) type-a ports quantity:	1
Usb 3.2 gen 2 (3.1 gen 2) type-c ports quantity:	1
Wi-fi:	No
Width:	305 mm
Windows operating systems supported:	Windows 10 x64, Windows 11 x64

Z790 PRO RS motherboard

Supports 13th and 12th generation Intel Core processors
14+1+1 phase power design, Dr.MOS for VCore+GT
4 x DDR5 DIMM, supports up to 6800+(OC)
1 PCIe 5.0 x16, 1 PCIe 4.0 x16, 2 PCIe 3.0 x1, 1 M.2 Key-E for Wi-Fi
Graphics output options: 1 HDMI, 1 DisplayPort, eDP
7.1-channel HD audio (Realtek ALC897 audio codec), Nahimic Audio
4 Hyper M.2 (PCIe Gen4x4), 8 SATA3
1 USB 3.2 Gen2 Type-C (Front), 1 USB 3.2 Gen2 Type-C (Rear), 1 USB 3.2 Gen2 Type-A (Rear), 6 USB 3.2 Gen1 (2 Rear, 4 Front), 8 USB 2.0 (4 Rear, 4 Front)
Realtek 2.5G LAN

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
