The WSS-412R amplifier is designed to work in cable networks (due to the return channel) and individual RTV antenna installationsThe power supply is carried out from a built-in AC adapter with LED signalingThe WSS-412R amplifier is designed for indoor use
AMPLIFIER WSS-412R 4x-12dB + K. ZWR TELMOR
€32.55
Shipping from warehouse: D4
Estimated shipping: Mon, Nov 25 - Thu, Nov 28
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Anttron
- Product code:
- ANTTRON-A414 / 5420037604142
Share this product:
Specification
| Amplification:: | 12 dB |
|---|---|
| Attenuation in the return channel:: | 2 dB |
| Connector type:: | "F" |
| Dimensions:: | 115 x 95 x 35 mm |
| Frequency range:: | 5 MHz ... 65 MHz, 85 MHz ... 862 MHz (OUT 1) 85 MHz ... 862 MHz (OUT 2-4) |
| Gain adjustment:: | 0 dB ... 12 dB |
| Ima3 60db:: | 105 dBμV |
| Input/output impedance:: | 75 Ω |
| Manufacturer / brand:: | TELMOR |
| Mismatch suppression:: | > 10 dB |
| Noise ratio:: | 4.5 dB |
| Number of inputs/outputs:: | 1 / 4 |
| Power consumption:: | 4 watts |
| Power:: | 230 VAC |
| Scales:: | 280 g |
| Separation between outputs:: | > 20 dB |
| Warranty:: | 2 years |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
