The WSS-218R amplifier is designed to work in cable networks (due to the return channel) and individual RTV antenna installationsThe power supply is carried out from a built-in AC adapter with LED signalingThe WSS-218R amplifier is designed for indoor use
AMPLIFIER WSS-218R 2x-18dB + K. ZWR TELMOR
€29.66
Shipping from warehouse: D4
Estimated shipping: Thu, Nov 14 - Mon, Nov 18
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Anttron
- Product code:
- ANTTRON-A217 / 5420037602179
Share this product:
Specification
| Amplification:: | 18 dB |
|---|---|
| Attenuation in the return channel:: | 6 dB |
| Connector type:: | "F" |
| Dimensions:: | 115 x 95 x 35 mm |
| Frequency range:: | 5 MHz ... 65 MHz85 MHz ... 862 MHz |
| Gain adjustment:: | 5 dB ... 18 dB |
| Ima3 60db:: | 105 dBμV |
| Input/output impedance:: | 75 Ω |
| Manufacturer / brand:: | TELMOR |
| Mismatch suppression:: | > 10 dB |
| Noise ratio:: | 4.5 dB |
| Number of inputs/outputs:: | 1 / 2 |
| Power consumption:: | 4 watts |
| Power:: | 230 VAC |
| Scales:: | 0.280 kg |
| Separation between outputs:: | > 20 dB |
| Warranty:: | 2 years |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
