MECHANICAL PARAMETERS:
Yield strength Re [N/mm2]: >420
Strength Rm [N/mm2]: 500-640
Elongation A5 [%]: >20
Impact strength Kv [J]:
>47J (-40°C)
>47J (-20°C), type. 90J
Electrode type (sheath): alkaline
Hydrogen content in the alloy: <5 ml/100 g, typ. 3,5 ml/100 g
Drying: 300 - 350°C / 2h8%
USABLE FEATURES:
Electrode with very good parameters, recommended for welding structures with normal and increased strength, heavily loaded dynamically, especially in the shipbuilding industry, machine building, rolling stock.
Designed for static and dynamic structures.
Recommended especially for the construction of elements that can not be rotated.
Yield about 118%.
Resistant to assembly and shipbuilding conditions. Weather-resistant coating - absorbs moisture the slowest of all electrodes in its class, so the electrode is especially recommended for the shipbuilding industry.
The focused and calm arc allows good observation of the lake during welding.
USE:
Shipbuilding
Dynamically loaded structures (e.g. outdoor advertising structures, lantern poles)
Pipes
Truck sides
Footbridges
