AHD CAMERA, HD-CVI, HD-TVI, PAL HAC-HDW1231TLMQ-A-0280B - 1080p 2.8 mm DAHUA

€46.57
Shipping from warehouse: ⁨D4⁩
Estimated shipping: Mon, Dec 30 - Thu, Jan 2
14 days returnUnconditional return policy
Availability:
moderate quantity
Brand:
Dahua
Product code:
HAC-HDW1231TLMQ-A-0280B / 6923172506658

Specification

Analog signal format system:NTSC, PAL
Angle of rotation:360°
Audio input channels:1 channels
Audio::Built-in Microphone, Support audio via coaxial cable - HD-CVI only
Back light compensation (blc):Yes
Bluetooth:No
Bnc output ports:1
Built-in hdd:No
Built-in microphone:Yes
Camera pan control:Yes
Camera shutter type:Electronic
Camera tilt control:Yes
Case::Dome, Metal + Plastic
Closest focusing distance:0.7 m
Colour::white
Connectivity technology:Wired
Day/night mode:Yes
Dc output voltage:12
Dc-in jack:Yes
Detect distance:43.9 m
Diameter:11 cm
Dimensions::Ø 110 x 88 mm
Ethernet lan:No
Fixed focal length:2.8 mm
Form factor:Dome
Frame rate:30 fps
Gain control type:Auto/Manual
Height:88.1 mm
Highlight compensation (hlc):Yes
Housing material:Plastic, Metal
Identify distance:4.4 m
International protection (ip) code:IP67
Ir illuminator power adjustment::Automatic
Ir illuminator range::30 m
Lens viewing angle, diagonal:127°
Lens viewing angle, horizontal:107°
Lens viewing angle, vertical:56°
Manual:Yes
Manufacturer / brand::DAHUA
Matrix size::2.1 Mpx
Maximum aperture number:1.6
Maximum resolution:1920 x 1080 pixels
Mirror:Yes
Mounting type:Ceiling/Wall/Pole
Noise reduction:Yes
Noise reduction technology:3D noise reduction
Number of cameras:1
Number of effective pixels (h x v):1920 x 1080 pixels
Objective::2.8 mm
Observe distance:17.5 m
Operating modes:AHD, CVI, TVI, CVBS
Operating temperature ::-40 °C ... 60 °C
Operating temperature (t-t):-40 - 60 °C
Optical sensor size:25.4 / 2.8 mm (1 / 2.8")
Osd menu::OSD menu available via DAHUA recorder
Package weight:450 g
Pan range:0 - 360°
Placement supported:Outdoor
Power consumption (max):3.1 W
Power consumption::≤ 3.1 watts
Power source type:DC
Power::12 VDC / 260 mA
Privacy masking:Yes
Product colour:White
Recognize distance:8.8 m
Resolution::1920 x 1080 - 1080p ,960 x 576 - 960H, PAL
S/n ratio::> 65 dB
Scales::0.33 kg
Sealing::IP67
Selected features::WDR - 130 dB - Wide Dynamic Range 3D-DNR - Digital Noise Reduction in BLC/HLC Image - Background Light / Strong Light Compensation ICR - Mechanical IR Filter Automatic White Balance Day/Night Mode AGC - Automatic Image Gain Adjustment Privacy Zones - Max. 8 Mirror - Sharpness Image Mirror - Sharpen Image Contours
Sensor type:CMOS
Signal-to-noise ratio (snr):65 dB
Smart ir:Yes
Standard::HD-CVI, HD-TVI, AHD, CVBS
Storage temperature (t-t):-40 - 60 °C
Supported graphics resolutions:1920 x 1080 (HD 1080), 960 x 576, 960 x 480
Supported video modes:480p, 1080p, 576p
Tilt angle range:0 - 78°
Total megapixels:2 MP
Transducer::1/2.8" Progressive Scan CMOS
Type:IP security camera
Video output::AHD / HD-CVI / HD-TVI / CVBS, 1 Vpp / 75 Ω
Viewing angle::107° (manufacturer data) 100° (our tests)
Warranty::3 years
Weight:280 g
White balance:Auto
Wi-fi:No
Wide dynamic range (wdr):Yes

Megapixel camera with 1/2.8" CMOS sensor and AHD / HD-CVI / HD-TVI / PAL interface

The range of the illuminator given by the manufacturer depends on the environmental conditions (air transparency, environment, wall color, i.e. the so-called scene reflectance)

The AHD / HD-CVI / HD-TVI interface allows the transmission of analog video signal via coaxial cable in max. 8 Mpx (4K UHD)There are no delays during transmission and the original, high image quality is maintained

In the case of video transmission by twisted pair and impedance matching transformers, it is important to bear in mind the possibility of signal reflections and signal penetration between each other

The camera meets ip67 protection class

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
