| Alarm signaling:: | LED, Signal for alarm control panel |
|---|---|
| Colour:: | white |
| Detection:: | Glass break sensor |
| Dimensions:: | 66 x 90 x 25 mm |
| Manufacturer / brand:: | PARADOX |
| Operating temperature:: | -20 °C ... 50 °C |
| Permissible load on relay contacts (resistive):: | 150 mA / 28 V DC |
| Power:: | 9 ... 16 VDC / 35 mA |
| Range:: | 9 m - high level, 4.5 m - low level |
| Scales:: | 0.056 kg |
| Selected features:: | plain, tempered and laminated glass break detection advanced microprocessor dual-track signal analysis self-diagnostic function BUS bus |
| Warranty:: | 2 years |
The sensor signals an alarm if it registers a low-frequency signal (impact sound) and a high-frequency signal (broken glass sound)A low-frequency sound wave caused by an impact causes the sensor to start analyzing the high-frequency channel
The recording of the sound of a shock wave by the microphone is indicated by the flashing of the LEDIf a high-frequency sound appears at this time, i.e. the sound of broken glass, the sensor triggers an alarm
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
